Modular Matrix Switcher
Comm-tec Srl 60 www.comm-tec.it
7. TCP/IP Control
7.1. Control Mode
TCP/IP default settings:
IP: 192.168.0.178,
Gateway is 192.168.0.1,
Serial Port: 4001.
IP and Gateway can be changed as you need, Serial Port cannot be changed.
● Controlled by Single PC
Connect a computer to the TCP/IP port of the MTX88M-N, and set its network segment to
the same as the default IP of the MTX88M-N (192.168.0.178).
