Comm-Tec MTX88M-N - EDID Management Command

Modular Matrix Switcher
Comm-tec Srl 34 www.comm-tec.it
Save[Y].
Store the current status to preset [Y].
[Y] ranges from 1 to 9.
Save To F8
Recall[Y].
Recall preset [Y]
Recall From F8
V: 01->001
A: 01->001
… …
Clear[Y].
Clear the preset [Y]
Clear F8
6.3.4. EDID Management Command
Command
Description
Feedback
UpgradeIntEDI
D[x].
Upgrade built-in EDID data. When the
command applied, system prompts to
upload the EDID file (.bin). [x] ranges 1 – 6.
Prompt to upload
EDID file
……..
Upload EDID to
system completed
EDIDUpgrade[x
].
Upgrade the EDID data of the input port
[x]. When the command applied, system
prompts to upload the EDID file (.bin).
Operation will be cancelled in 10 seconds.
Prompt to upload
EDID file
……..
Upload EDID to
input card
completed
EDID/[x]/[y].
Set the built-in EDID data type [y] to input
port [x]. [y]= 1~6.
Set system EDID[y]
to input [x]
EDIDG[x].
Get the EDID data from output port [x] and
display on serial port.
EDIDMInit.
Reset all input card EDID to all input card
EDIDMInit
EDIDM[x]B[y].
Set the EDID data of output [x] on input
[y].
EDIDM2B1
