Comm-Tec MTX88M-N - VH Output Card Command

Modular Matrix Switcher
Comm-tec Srl 40 www.comm-tec.it
6.3.8. 4O-VH Output Card Command
Command
Description
Feedback
USER/O/[x]:0201%;
Set the VGA output [x] to YPbPr signal.
0201%
USER/O/[x]:0202%;
Set the VGA output [x] to VGA signal.
0202%
USER/O/[x]:0203%;
Set the VGA output [x] to C-VIDEO
signal.
0203%
USER/O/[x]:0110%;
Enable the analog audio output [x].
0110%
USER/O/[x]:0111%;
Disable the analog audio output [x].
0111%
GetVGAPortMode[x]
.
Get the port status of output [x].
USER/O/[x]:0800%;
Set the resolution of output [x] to
720x480i@60Hz.
Resolution
Ou01 720x480 I
USER/O/[x]:0801%;
Set the resolution of output [x] to
720x576i@50Hz.
Resolution
Ou01 720x576 I
USER/O/[x]:0802%;
Set the resolution of output [x] to
720x480P@60Hz.
Resolution
Ou01 720x480 P
USER/O/[x]:0803%;
Set the resolution of output [x] to
720x576p@50Hz.
Resolution
Ou01 720x576 P
USER/O/[x]:0804%;
Set the resolution of output [x] to
1280x720P@60Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0805%;
Set the resolution of output [x] to
1280x720P@59Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0806%;
Set the resolution of output [x] to
1280x720P@50Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0807%;
Set the resolution of output [x] to
1280x720P@30Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0808%;
Set the resolution of output [x] to
1280x720P@25Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0809%;
Set the resolution of output [x]
to1280x720P@24Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0810%;
Set the resolution of output [x]
to1920x1080i@60Hz.
Resolution
Ou01 1920x1080I
USER/O/[x]:0811%;
Set the resolution of output [x]
to1920x1080i@59Hz.
Resolution
Ou01 1920x1080I
USER/O/[x]:0812%;
Set the resolution of output [x]
to1920x1080i@50Hz.
Resolution
Ou01 1920x1080I
USER/O/[x]:0813%;
Set the resolution of output [x]
to1920x1080P@60Hz.
Resolution
Ou01 1920x1080P
USER/O/[x]:0814%;
Set the resolution of output [x]
Resolution
