Comm-Tec MTX88M-N - SS Output Card Command; BT Input Card Command; BTS Input Card Command

Modular Matrix Switcher
Comm-tec Srl 53 www.comm-tec.it
6.3.19. 4O-SS Output Card Command
Command
Description
Feedback
USER/O/[x]:0804%;
Set the resolution of output [x] to
1280x720P@60Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0806%;
Set the resolution of output [x] to
1280x720P@50Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0810%;
Set the resolution of output [x]
to1920x1080i@60Hz.
Resolution
Ou01 1920x1080I
USER/O/[x]:0812%;
Set the resolution of output [x]
to1920x1080i@50Hz.
Resolution
Ou01 1920x1080I
USER/O/[x]:0813%;
Set the resolution of output [x]
to1920x1080P@60Hz.
Resolution
Ou01 1920x1080P
USER/O/[x]:0815%;
Set the resolution of output [x] to
1920x1080P@50Hz.
Resolution
Ou01 1920x1080P
USER/O/[x]:0816%;
Set the resolution of output [x] to
1920x1080P@30Hz.
Resolution
Ou01 1920x1080P
6.3.20. 4I-BT Input Card Command
Command
Description
Feedback
AUDIO[x]I[z].
Select audio source for input [x]
[x] is port number; [z] stands for audio
source, it can be 0 (embedded HDMI
audio) or 1 (analog audio)
AUDIO1I0.
6.3.21. 4I-BTS Input Card Command
Command
Description
Feedback
USER/I/[x]:02xx%;
Set the image brightness of input [x] to
xx, xx=00~99.
0299%
USER/I/[x]:03xx%;
Set the image contrast of input [x] to xx,
xx=00~99.
0399%
USER/I/[x]:04xx%;
Set the image saturation of input [x] to
xx, xx=00~99.
0499%
USER/I/[x]:05xx%;
Set the image sharpness of input [x] to
xx, xx=00~99.
0599%
USER/I/[x]:0606%;
Automatically calibrate the VGA signal
of input [x].
0606%
USER/I/[x]:0607%;
Set the image color temperature of
input [x] to user/cool/medium/warm.
0607%
USER/I/[x]:0608%;
Set the image aspect ratio of input [x] to
16:9/4:3/Auto/Panorama/Just
scan/Zoom2/Zoom1.
0608%
USER/I/[x]:0614%;
Set the image mode of input [x] to
0614%
