audio source for input [x].
6.3.10. 4O-HS Output Card Command
Command
Description
Feedback
USER/O/[x]:0804%;
Set the resolution of output [x] to
1280x720P@60Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0813%;
Set the resolution of output [x]
to1920x1080P@60Hz.
Resolution
Ou01 1920x1080P
USER/O/[x]:0824%;
Set the resolution of output [x] to
1024x768p@60Hz.
Resolution
Ou01 1024x768
USER/O/[x]:0826%;
Set the resolution of output [x] to
1280x1024p@60Hz.
Resolution
Ou01 1280x1024
USER/O/[x]:0837%;
Set the resolution of output [x] to
1920x1200P@60Hz.
Resolution
Ou01 1920x1200
GetResolution[x].
Get the resolution of output [x].
USER/O/[x]:0617%;
Restore the output [x] signal card to
factory default.
USER/O/[x]:0110%;
Enable the analog audio output [x].
0110%
USER/O/[x]:0111%;
Disable the analog audio output [x].
0111%
6.3.11. 4I-UH Input Card Command
Command
Description
Feedback
AUDIO[x]I[z].
Select audio source for input [x]
[x] is port number; [z] stands for audio
source, it can be 0 (embedded HDMI
audio) or 1 (analog audio)
AUDIO1I0.
6.3.12. 4I-SH Input Card Command
Command
Description
Feedback
USER/I/[x]:02xx%;
Set the image brightness of input [x] to
xx, xx=00~99.
0299%
USER/I/[x]:03xx%;
Set the image contrast of input [x] to xx,
xx=00~99.
0399%
USER/I/[x]:04xx%;
Set the image saturation of input [x] to
xx, xx=00~99.
0499%
USER/I/[x]:05xx%;
Set the image sharpness of input [x] to
xx, xx=00~99.
0599%
USER/I/[x]:0607%;
Set the image color temperature of
input [x] to user/cool/medium/warm.
0607%
USER/I/[x]:0608%;
Set the image aspect ratio of input [x] to
16:9/4:3/Auto/Panorama/Just
0608%
