Comm-Tec MTX88M-N - Signal Card

Modular Matrix Switcher
Comm-tec Srl 8 www.comm-tec.it
1.2. Signal Card
The matrix supports multiple signal cards as listed in the following charts:
Signal
Model
Description
VGA
4I-VA
1080P seamless VGA input card with 4 VGA and 4
external L+R audio ports.
4O-VG
1080P VGA output card with 4 VGA and 4 external
stereo audio ports.
4O-VS
1080P seamless VGA output card with 4 VGA and 4
external L+R audio ports.
VGA+HDMI
4I-VH
1080P seamless VGA+HDMI input card with 2 VGA, 2
HDMI and 4 external L+R audio ports.
4O-VH
1080P seamless VGA+HDMI output card with 2 VGA, 2
HDMI and 4 external L+R audio ports.
HDMI
4I-HS
1080P seamless HDMI input card with 4 HDMI and 4
external L+R audio ports.
4O-HS
1080P seamless HDMI output card with 4 HDMI and 4
external L+R audio ports.
4I-UH
4K HDMI input card with 4 HDMI, and 4 external L+R
audio ports.
4O-UH
4K HDMI output card with 4 HDMI and 4 external L+R
audio ports.
SDI
4I-SS
1080P seamless SDI input card with 4 SDI input and 4
loop output ports.
4O-SS
1080P seamless SDI output card with 4 SDI output and
4 loop output ports.
SDI+HDMI
4I-SH
1080P seamless SDI+HDMI input card with 2 SDI, 2
SDI LOOP, 2 HDMI and 2 external L+R audio ports.
4O-SH
1080P seamless HDMI+SDI output card with 2 SDI, 2
SDI LOOP, 2 HDMI and 2 external L+R audio ports.
CVBS
4I-AV
1080P seamless CVBS input card with 4 CVBS and 4
external L+R audio ports.
4O-AV
1080P seamless CVBS output card with 4 CVBS and 4
external L+R audio ports.
DVI
4I-DS
1080P seamless DVI input card with 4 DVI ports.
4O-DS
1080P seamless DVI output card with 4 DVI ports.
HDBaseT
4I-BT
4K HDBaseT input card with 4 HDBT, 4 RS232 and 4
external stereo audio ports.
4O-BT
4K HDBaseT output card with 4 HDBT, 4 RS232 and 4
external stereo audio ports.
4I-BTS
1080P seamless HDBaseT input card with 4 HDBT, 4
RS232 and 4 external stereo audio ports.
4O-BTS
1080P seamless HDBaseT output card with 4 HDBT, 4
RS232 and 4 external stereo audio ports.
OPTICAL
4I-UFS
1080P seamless OPTICAL input card with 4 OPTICAL
ports.
