Comm-Tec MTX88M-N - SH Output Card Command

Modular Matrix Switcher
Comm-tec Srl 44 www.comm-tec.it
scan/Zoom2/Zoom1.
USER/I/[x]:0614%;
Set the image mode of input [x] to
user/Dynamic/Standard/mild.
0614%
USER/I/[x]:0617%;
Restore the input [x] signal card to
factory default.
0617%
USER/I/[x]:0619%;
Set the resolution of input [x] to
1360x768 HD.
0619%
USER/I/[x]:0626%;
Set the resolution of input [x] to
1024x768 XGA.
0626%
USER/I/[x]:0627%;
Set the resolution of input [x] to
1280x720 720P.
0627%
USER/I/[x]:0628%;
Set the resolution of input [x] to
1280x800 WXGA.
0628%
USER/I/[x]:0629%;
Set the resolution of input [x] to
1920x1080 1080P.
0629%
USER/I/[x]:0620%;
Set the resolution of input [x] to
1920x1200 WUXGA.
0620%
USER/I/[x]:0621%;
Set the resolution of input [x] to
1600x1200 UXGA.
0621%
USER/I/[x]:0698%;
Upgrade the software of input [x].
0698%
USER/I/[x]:0711%;
Select HDMI embedded audio as audio
source for input [x].
0711%
USER/I/[x]:0712%;
Select external analog audio input as
audio source for input [x].
0712%
6.3.13. 4O-SH Output Card Command
Command
Description
Feedback
USER/O/[x]:0110%;
Enable the analog audio output [x].
0110%
USER/O/[x]:0111%;
Disable the analog audio output [x].
0111%
The below commands used for HDMI ports.
USER/O/[x]:0800%;
Set the resolution of output [x] to
720x480i@60Hz.
Resolution
Ou01 720x480 I
USER/O/[x]:0801%;
Set the resolution of output [x] to
720x576i@50Hz.
Resolution
Ou01 720x576 I
USER/O/[x]:0802%;
Set the resolution of output [x] to
720x480P@60Hz.
Resolution
Ou01 720x480 P
USER/O/[x]:0803%;
Set the resolution of output [x] to
720x576p@50Hz.
Resolution
Ou01 720x576 P
USER/O/[x]:0804%;
Set the resolution of output [x] to
Resolution
