6.3. RS232 Communication Command
With this command system, users are able to control and operate the matrix with RS232
software remotely.
Note:
● Please disconnect all the twisted pairs before sending command EDIDUpgrade[X].
● In the commands, “[”and “]” are symbols for easy reading and do not need to be typed
in actual operation.
● Please remember to end the commands with the ending symbols “.” or “;”.
● Type the command carefully, it is case-sensitive.
● Commands pertaining to EDID only avails for signal cards that support EDID
management.
● The matrix boasts 6 in-built EDID data, the chart below illustrates the detailed
information:
No.
Detailed Information
1
1080P 2D 5.1CH
2
1080P 2D 2.0CH
3
720P 2D 5.1CH
4
720P 2D 2.0CH
5
4kx2k 2D 5.1CH
6
4kx2k 2D 2.0CH
Update in-built EDID data by sending command UpgradeIntEDID[x]..
Communication protocol:
Baud rate: 9600;
Data bit: 8;
Stop bit: 1;
Parity bit: none.
