8. Specification
8.1. Main Unit
Control Part
Serial Control Port
RS232, 9- female D connector
Configuration
2 = TX, 3 = RX, 5 = GND
Installation
Rack Mountable
Front Panel Control
Buttons
Option
TCP/IP control
General
Power Supply
100VAC ~ 240VAC, 50/60Hz
Power Consumption
23W (Max, no load)
Operation Temperature
-10℃ ~ +55℃
Storage Temperature
-25℃ ~ +70℃
Relative Humility
10%-90%
Dimension (W*H*D)
483mm x 88mm x 320mm (2U high)
Net Weight
About 3KG (No signal card)
8.2. Signal Card
8.2.1. 4I-VA
Video
Input
(4) VGA
Input Connector
(4) Female 15-pin HD VGA
Input Level
0.5 ~ 2.0Vp-p
Input Impedance
75Ω
Audio
Input
(4) Audio
Input Connector
(4) 3-pin pluggable terminal block
CMRR
20Hz ~ 20KHz
Input Impedance
>10KΩ
General
Gain
0 dB
Bandwidth
YPbPr:170MHz; C-video:150MHz; VGA:170MHz
Video Signal Format
VGA (RGBHV), YPbPr, S-video, C-video
Audio Signal Format
PCM
Resolution
Up to 1080P@60Hz
Crosstalk
<-50dB@5MHz
