8.2.2. 4O-VG
Video
Output
(4) VGA
Output Connector
(4) Female 15-pin HD VGA
Output Level
0.5 ~ 2.0Vp-p
Output Impedance
75Ω
Audio
Output
(4) Audio
Output Connector
(4) 3.5mm mini jack
CMRR
20Hz ~ 20KHz
Output Impedance
75Ω
General
Bandwidth
350MHz (-3dB)
Crosstalk
<-50dB@5MHz
Video Signal Format
VGA
Audio Signal Format
PCM
Resolution
Up to 1080P@60Hz
Crosstalk
<-50dB@5MHz
8.2.3. 4O-VS
Video
Output
(4) VGA
Output Connector
(4) Female 15-pin HD VGA
Output Level
0.5 ~ 2.0Vp-p
Output Impedance
75Ω
Audio
Output
(4) Audio
Output Connector
(4) 3-pin pluggable terminal block
CMRR
20Hz ~ 20KHz
Output Impedance
75Ω
General
Gain
0 dB
Bandwidth
340MHz(-3dB)
Video Signal Format
VGA (RGBHV), YPbPr, C-video
Audio Signal Format
PCM
Resolution
Up to 1080P@60Hz
Crosstalk
<-50dB@5MHz
