8.2.7. 4I-SS & 4O-SS
4I-SS
Input
(4) SDI
Input Connector
(4) Female BNC
Color Depth
8, 10, 12 bit
Input Level
T.M.D.S 2.9V～3.3V
Input Impedance
75Ω
4O-SS
Output
(4) SDI
Output Connector
(4) Female BNC
Color Depth
8 bit
Output Level
T.M.D.S 2.9V～3.3V
Output Impedance
75Ω
General
Video Signal Format
SDI, HD-SDI, 3G-SDI
Resolution
Up to 1080P@60Hz
Transmission Distance
1080P≤60m
Color Depth
8, 10, 12 bit
Bandwidth
6.75Gpbs
8.2.8. 4I-SH & 4O-SH
4I-SH
Input
(2) SDI, (2) HDMI, (2) Audio
Input Connector
(2) Female BNC,
(2) Female 19-pin type-A HDMI,
(2) 3-pin pluggable terminal block
Color Depth
8, 10, 12 bit
Input Level
T.M.D.S 2.9V～3.3V
Input Impedance
75Ω
4O-SH
Output
(2) SDI, (2) HDMI, (2) Audio
Output Connector
(2) Female BNC,
(2) Female 19-pin type-A HDMI,
(2) 3-pin pluggable terminal block
Color Depth
8 bit
Output Level
T.M.D.S 2.9V～3.3V
Output Impedance
75Ω
General
Video Signal Format
SDI: SDI, HD-SDI, 3G-SDI
HDMI: HDMI, DVI
Audio Signal Format
PCM
Resolution
Up to 1080P@60Hz
Transmission Distance
1080P≤60m
