and press RETURN. The Commodore 128 displays a sprite grid
on the 40 column screen, ln addition, the computer displays the
prompt:
SPRITE NUMBER ?
Enter a number between 1 and 8. The computer displays the
corresponding sprite in the upper right corner of the screen. From
now on, we will refer to the sprite grid as the work area. The work
area has the dimensions of 24 characters wide by 21 characters
tall. Each character position within the work area corresponds to
1 pixel within the sprite, since a sprite is 24 pixels wide by 21
pixels tall. While within the work area in SPRDEF mode, you have
several editing commands available to you. Here’s a summary of
the commands:
Sprite Definition Mode Command Summary
CLR key—Erases the entire work area
M key—Turns on/off multicolor sprite
CTRL 1 -8—Selects sprite foreground color 1 -8
C* 1 -8—Selects sprite foreground color 9-16
1 key—Turns on pixels in the background color
2 key—Turns on pixels in the foreground color
3 key—Turns on areas in multicolor 1
4 key—Turns on areas in multicolor 2
A key—Turns on/off automatic cursor movement
CRSR keys—Moves the cursor (+) within the work area
RETURN—moves cursor to the start of the next line
HOME key—Moves cursor to the top left corner of work
area.
X key—Controls horizontal expansion
Y key—Controls vertical expansion
Shift RETURN—Saves sprite from work area and returns to
SPRITE NUMBER prompt
C key—copies one sprite to another
STOP key—Turns off displayed sprite and returns to SPRITE
NUMBER prompt without changing the sprite
RETURN key—(at SPRITE NUMBER prompt) Exits SPRDEF
mode
6-25
