ComNav 1500 - Page 25

ComNav 1500 / 1510 Autopilot - 18 -
Helm
Pump
Filler vent plug
Pumpset
Tiller
Rudder
Steering
Cylinder
TEE FITTING MUST BE
INSTALLED POINTING
UPWARDS AS SHOWN.
R
E
S
E
R
V
O
I
R
P
O
R
T
G
R
A
D
U
A
L
R
I
S
E
OPTION PF0.3 PUMPSET
G
R
A
D
U
A
L
R
I
S
E
R
E
S
E
R
V
O
I
R
P
O
R
T
TEE FITTING MUST BE
INSTALLED POINTING
UPWARDS AS SHOWN.
Helm
Pump
Pumpset
Tiller
Rudder
Steering
Cylinder
OPTION PV1.4 PUMPSET
ComNav PV Series Pumpset
with Teleflex 250V & 275V
systems. Mount Teleflex
Uniflow Valve at least 6' (2m)
from helm pump.
Filler vent plug
