ComNav 1500 / 1510 Autopilot
Temperature range:
The above products have the same temperature range.
Storage: -30°C to +80°C ( -22°F to 176°F)
Operation: -10°C to +70°C (14°F to 158°F)
12.5 Pumpsets
Enclosure: Splashproof
Ambient Temperature Range: -5°C to +50°C
Model Max.
Flow
(GPM)
Max.
Pressure
(PSI)
Max.
Current
(A)
Average
Current
(A)
PF0.3 0.3 1000 20 2-3
PV1.4 1.4 400 20 4-6
12.6 Linear Drive
Enclosure: Splashproof
Ambient Temperature Range: -5°C to +50°C
12 seconds
2 x 50
1600 lb.
12 or 24 VDC
Rudder Speed:
Max. Rudder Angle:
Max. Force:
12.7 Solenoid Valve Drive
Voltage:
Max
. Current:
15 Amp
12.8 NX2 Network Specification
The NX2 Network is a high performance, non-collision multi-talker, multi-receiver
data bus, specially designed for marine navigation applications. The most important
features are the high update rate, fast response times, very low data latency
(25ms) and very high data security even at long distances. Another important
feature is that data transfer efficiency will not degrade even when used in large and
complex systems. It utilizes the RS485 standard with up to 32 senders and/or
receivers to form a Local Area Network. Data is transmitted asynchronously with 1
start-bit, 8-data-bits, 1 parity-bit, two stop-bits in 9600 baud.
The link between NX2 Network and your PC-application is the PC interface FD (Full
Duplex) / NMEA (PN 20620010). This is supplied with a 9-pole D-sub connector on
a 1m (3.3 ft) cable for the RS232 PC port. The PC interface is a useful tool to
monitor and log real time data, or when editing waypoints to/from PC-file or to/from
NX2 Network.
CE Approval:
The above products conform to the EMC requirements for immunity and emission
according to EN 5008-1 and EN 55022.
- 57 -
