ComNav 1500 - Using the Control Buttons

ComNav 1500 / 1510 Autopilot - 27 -
4.2 How to Use the Push-Buttons
4.2.1 MODE
A press on MODE, moves one page to the right, indicated
by the page-arrow at top of the display.
In edit mode, a press on MODE moves the cursor one step
to the right. If the cursor is at the farthest right hand side,
a further press will cause it to rotate back to the left hand side.
4.2.2 LEFT
When the Autopilot is activated, a short press on LEFT
decreases the course by 1°, a long press decreases
the course by 10°.
In setup mode a press on LEFT moves to the previous setup
function. In edit mode a press on LEFT decreases a digit
by one.
4.2.3 RIGHT
When the Autopilot is activated, a short press on RIGHT
Increases the course by 1°, a long press increases
the course by 10°. In setup mode a press on RIGHT
moves to the next setup function. In edit mode a press on
RIGHT increases a digit by one.
4.2.4 SET
A press on SET engages the Autopilot in the selected steering
function (HDG, NAV WIND, or PWR ST).
In Setup Mode, a press on SET unlocks a digit to access edit
mode. When unlocked, the digits are ”active” (flashes) and can
be edited by pressing LEFT, RIGHT and MODE as required.
When finished editing, lock the digit by another press on SET.
4.2.5 OFF
A press on OFF turns the Autopilot.
4.2.6 Tack
A press on LEFT and RIGHT together, performs a Tack
when steering in wind mode.
&
