ComNav 1500 / 1510 Autopilot - 46 -
If the APC fails: Error message 34 (calibration failure) is displayed. This is most
likely caused by too much air still in the system. To escape the error message,
press any push-button. Revert to 10.3. ”How to remove air from the system”. Note!
You can ”help” the APC process by manually pulling the steering wheel or tiller in
same direction as APC turns the boat to pass the APC.
If the APC is successful: All 4 page-arrows disappear, the instrument leaves the
setup mode and returns to standby mode automatically.
Note! You may interrupt the APC routine at any time by a press on SET.
Congratulations, your Autopilot calibration is done.
Now go ahead and activate the Autopilot and enjoy the NX2 performance.
