ComNav T300 + CGSurvey User Guide
25
5.2 Radio Mode
Radio mode is that the correction data is transmitted via radio communication in real
time. ComNav T300 GNSS Receiver is equipped with internal transmitting & receiving
radio, the following will explain T300 T/x + T300 R/x RTK operation.
T300 Internal Radio Specifications:
Radio parameter
Specifications
Frequency range
Tx range: 458 MHz-469 MHz， Rx range: 450-470MHz
Protocol
Transmit mode: Transparent
Receiving mode: MAC(compatible with CHC protocol), TT450S,
Transparent and south protocol.
Airlink rate
9600 bps
Bandwidth
12.5kbps
Power
0.5, 1, 2 Watt adjustable
Work distance
3-4km, depends on environment and power setting
Prerequisites
 Two kits T300 GNSS receiver
All T300 GNSS receivers can be worked as either Base or Rover.
 Use external power source and power cable to supply power to T300 Base
station (When T300 in base mode and transmitting via internal radio, the
