ComNav T300 + CGSurvey User Guide
14
4 Static Mode
This chapter describes how to use T300 for static survey. According to the workflow
of static survey, we will explain the operation in the following 5 sections--receiver
configuration, default setting, static data download, convert data to Rinex format and
receiver memory management.
4.1 Static Mode Configuration
Use CRU (Compass receiver utility) software to configure T300. You can download
the software from the below link:
http://www.comnavtech.com/download.asp?bigclassid=28
After download and install software (install the USB drive) , please follow the step to
configure T300.
Tips: There are two kinds of cable can be used for static configuration, 7Pin Lemo to USB or 7
pin Lemo to RS232. Here we suggest use 7 pin Lemo to USB cable, it is more convenient.
Power on receiver, press the function panel twice shortly, and then the yellow
LED will light on, it means the receiver in configuration mode.
Use the 7 pin LEMO (link with T300 LEMO) to USB (link with PC) cable to build
connection from receiver to pc, then in PC it will indicate to find the new
hardware and ready for use.
Run the software CRU and click icon , in the Serial port Com option, you
will find the USB option, and then click OK to make the receiver connect with
your computer. If the connection is successful, you will see the SN No. of
receiver in the left top icon of CRU software.
