The power supply controls many functions and components. To determine if the
power supply is functioning properly, start with Procedure 1 and continue with the
other Procedures as instructed. The flowchart in Figure 6-2 gives a summary of the
process.
The procedures described in this section are:
 Procedure 1: Power status check
 Procedure 2: Adaptor / battery replacement
 Procedure 3: Power supply connection check
 Procedure 4: Diagnostic check
 Procedure 5: Internal connection check
3.1 Procedure 1 Power Status Check
The following LEDs indicate the power supply status:
Battery LED
The power supply controller displays the power supply status through the Battery and
the POWER LEDs as listed in the tables below.
 Table 2-1 Battery LED
Battery State
LED colors
Definition
Charging
blue, blinking
Battery charging with AC
blue, solid on
Battery fully charged by AC
color off
Battery abnormal: stop charging with AC
(Bad cell/ Overheated)
Discharging
Amber, blinking
LED on for 1
second every 4
seconds
Battery within low state: 12 minutes remaining
Amber, blinking
(LED on 1 second
every 2 seconds)
Battery within critical low state: 3 minutes
remaining. The system is protected and cannot
be re-powered on without the AC power
connected.
Color off
Battery not in low or critical low state; in
discharging state
