1-9
Compaq ProLiant 800 Server Reference Guide
Writer: Project: Compaq ProLiant 800 Features Comments:
File Name: C-ch1.doc Last Saved On: 4/23/97 11:09 AM
Figure 1-7. ProLiant 800 server drive positions
Table 1-3
Description of Drive Bays
Drive
Position
Configuration
1 Standard internal hard drive; 1” form factor
2 3.5” standard diskette drive
3 5.25” half-height drive bay (removable media area)
4 5.25” half-height drive bay (removable media area)
5 5.25” half-height drive bay occupied by standard CD-ROM drive (removable
media area)
Processor Boards/Power Module
200/66 256-KB cache and 180/60 256-KB cache Pentium Pro
Dual Pentium Pro processor capability
Processor Power module (DC-to-DC converter)
