1-4 Compaq ProLiant 800 Features
Writer: Project: Compaq ProLiant 800 Features Comments:
File Name: C-ch1.doc Last Saved On: 4/23/97 11:09 AM
When the hard drive activity light or diskette drive activity light is on,
the drive is either reading information from the disk or storing information on
the disk. Button
ejects the diskette from the floppy drive.
Removing the Side Access Panel
To remove the side access panel:
1. If the server is on, turn it off and disconnect the power cord.
2. Loosen the three thumbscrews on the rear of the unit.
3. Slide the side access panel toward the rear of the unit.
4. Lift and remove the panel.
Figure 1-3. Removing the side access panel
