3-12 Installing Hardware Options
Writer: Project: Installing Hardware Options Comments:
File Name: E-ch3.doc Last Saved On: 4/23/97 11:22 AM
NOTE: Each processor comes with a Processor Power module that must be
installed before you power up the server.
8. Install the Processor Power module (DC-to-DC converter). See the next
section, “Installing a Processor Power Module.”
9. Replace the expansion backplane brace as described in the section
“Replacing the Expansion Backplane Brace.”
10. Replace the side access panel.
11. Run the System Configuration Utility. See Chapter 5, "Using the
Compaq System Configuration Utility."
Installing a Processor Power Module
Every Pentium Pro Processor comes with a Processor Power module (DC to
DC converter) that provides power stability for the processor and the I/O
board.
The Processor Power module is keyed to ensure correct alignment. A notch in
the bottom edge of the module, near the center, must align with a tab in the
mounting bracket. The notch and tab will not line up if the module is turned
the wrong way.
