3-8 Installing Hardware Options
Writer: Project: Installing Hardware Options Comments:
File Name: E-ch3.doc Last Saved On: 4/23/97 11:22 AM
5. Slide the expansion board into the expansion slot and press it firmly
into place.
Figure 3-5. Sliding an expansion board into an expansion slot
6. Replace the screw at the side of the expansion slot.
7. Replace the expansion board cage into the server chassis.
