3-24 Installing Hardware Options
Writer: Project: Installing Hardware Options Comments:
File Name: E-ch3.doc Last Saved On: 4/23/97 11:22 AM
SCSI hard drives on the Integrated 32-bit Wide-Ultra SCSI controller must be
either internal or in an external storage system, but not both.
!
WARNING: The ProLiant 800 server does not support the installation of
IDE or EIDE fixed disk drives.
Figure 3-19. Optional mass storage device placement
Table 3-2
Mass Storage Bay Locator
Position Identifier Position Description
Mass Storage Bay 0
Mass Storage Bay 1
Mass Storage Bay 2
Mass Storage Bay 3
Mass Storage Bay 4
