Pos Qty. Art. no. Description Note
3
-45010 1824 Cutter housing 1-st 2-nd 5-th Basic version of cutter house
3-45088 1824 Cutter housing 5-th 2-nd Cutter house for bulky items
3-45089 1824 Cutter housing 3-rd 2-nd 5-th Cutter house for precutting
3
-45030 1836 Cutter housing 1-st 2-nd 5-th Basic version of cutter house
3-45038 1836 Cutter housing 5-th 2-nd Cutter house for bulky items
3-45045 1836 Cutter housing 3-rd 2-nd 5-th Cutter house for precutting
3-45046 1848 Cutter housing 1-st 2-nd 5-th Basic version of cutter house
3-45073 1848 Cutter housing 5-th 2-nd Cutter house for bulky items
3-45074 1848 Cutter housing 3-rd 2-nd 5-th Cutter house for precutting
11111111111-45104 Side left
21111111111-45105 Side right
3111------1-45100 Front side
---111--- 1-45106 – ” –
------111 1-45110 – ” –
41--------1-45101 Back side
-1------- 1-45103 – ” –
--1------ 1-45102 – ” –
---1----- 1-45107 – ” –
----1---- 1-45109 – ” –
-----1--- 1-45108 – ” –
------1-- 1-45111 – ” –
-------1- 1-45113 – ” –
--------1 1-45112 – ” –
522-2-22-22-45117 Side, inner
--2-2--2- 2-45174 – ” –
6111------1-45686 Holder
---111--- 1-45118 – ” –
------111 1-45424 – ” –
71--------2-45683 Support rule, left 1-st
---1----- 2-45138 – ” – 1-st
------1-- 2-45435 – ” – 1-st
81--------2-45684 Support rule, right 1-st
---1----- 2-45139 – ” – 1-st
------1-- 2-45436 – ” – 1-st
9111------2-45681 Support rule, left 2-nd
---111--- 2-45140 – ” – 2-nd
------111 2-45433 – ” – 2-nd
10 111------ 2-45682 Support rule, right 2-nd
---111--- 2-45141 – ” – 2-nd
------111 2-45434 – ” – 2-nd
11 111------ 2-45679 Support rule, left 5-th
---111--- 2-45142 – ” – 5-th
------111 2-45431 – ” – 5-th
12 111------ 2-45680 Support rule, right 5-th
---111--- 2-45143 – ” – 5-th
------111 2-45432 – ” – 5-th
13 --2------ 2-45685 Support rule 3-rd
-----2--- 2-45176 – ” – 3-rd
--------2 2-45439 – ” – 3-rd
14 222222222 3-45149 Shaft, hinge
15 111111111 4-45654 Guide, front side
16 111111111 4-45655 Guide, side, right
17 111111111 940134 Screw M16
18 111111111 940566 Screw M10
19 111111111 950645 Handle
20 222222222 950644 Parallel pin
21 444444444 950667 Parallel pin
22 777777777 940392 Nut M20
23 111111111 940600 Screw M20
24 12 8 12 12 8 12 12 8 12 940862 Grub screw
25 17 11 17 17 11 17 17 11 17 940072 Screw M20
26 222222222 940097 Screw M8
27 10 10 10 10 10 10 10 10 10 940211 Screw
28 888888888 940819 Screw
29 111111111 940825 Grub screw M10
30 666666666 960220 Slide bearing
31 444666666 940703 Screw
32 -6--6--6- 940003 Screw M10
33 -6--6--6- 940020 Washer
8.1 Cutter Housing (continued)
8-4 l Spare Parts Lis t
