Maintenance l 5-17
5.8 Close the screen box, granule
bin, cutter house door and hopper
(continued)
Close the cutter house door
9 NOTE: The hopper must be closed before closing the cutter house door.
NOTE: Never use help when closing the door to the cutter house.
Close the door to the cutter house alone. The cutter house door is heavy!
The risk of injuring fingers or hands increases when two or more persons
works, to close the cutter house door. Be careful!
10 Close the cutter house door.
11 First pull the lock handle outwards and then
lift the lock handle upwards.
12 Fasten the screws “L”, hex wrench 22 mm.
L
5
Maintenance
