The new disablement is also added in the disablements list under: Menu » 3
Disablements » 2 Disable. list
5.6.4 Disabling Zones
(Access level 2B or higher)
Disabling an Addressable Zone
NOTE!
Disablements of something belonging to a safety critical function is restricted to
timer disablement. This function requires at least access level 2B.
1 Select Menu » 3 Disablements » 1 New disablement » 1 Zones
2 Choose Zone (Zone number)
3 Choose unit type (Smoke detectors, All detectors, Heat detectors, Flame detectors or
Manual Call Points)
4 Choose disablement type Permanent
5.6.5 Disabling Addressable Detectors & Manual Call
Points
(Access level 2B or higher)
NOTE!
Disabling of individual detectors is only possible on addressable loops.
NOTE!
Disablements of something belonging to a safety critical function is restricted to
timer disablement. This function requires at least access level 2B.
1 Select Menu » 3 Disablements » 1 New disablement » 2 Det. & Call Points
2 Choose zone (Zone number)
3 Choose unit type (Smoke detectors, All detectors, Heat detectors, Flame detectors or
Manual Call Points)
4 Choose unit from list
5 Choose disablement type Permanent
CAUTION!
The timer disablement also applies to disablement type Permanent. The disablement
time depends on Max disablement time set in the CCP configuration, refer to the
Application Programming Manual.
5.7 Reconnecting
5.7.1 Reconnecting Disabled Items
All disablements in the system are presented in the disablement list. Any
reconnection is made from this list.
