User Manual 7Fault codes
5100606_CFD5000 T - CM2.2_User Manual_T_EN_2023_E
37
Fault Code
Unit or
Module
Cause Remedy Failure classification
141
CABLE
BREAK
POSITIVE
CS-Loop M
A cable break on the
positive conductor on
the CS-Loop M has
been detected. (Only
for a non-redundant
loop.)
Locate the cable break.
(Refer to the I&C* manual.)
•
Minor fault if in no
combination with
other faults.
•
Major fault if in
combination with
other faults.
142
CABLE
BREAK
NEGATIVE
CS-Loop M
A cable break on the
negative conductor on
the CS-Loop M has
been detected. (Only
for a non-redundant
loop.)
Locate the cable break.
(Refer to the I&C* manual.)
•
Minor fault if in no
combination with
other faults.
•
Major fault if in
combination with
other faults.
143
COMMUNI-
CATION
ERROR
CM 4.3
CM 2.2
CS-Loop M
CS-Safety M
CS-Com M
Loop units
Fault reported when
the communication
within a loop-line fails
more than 10% of the
communicate attempts
with loop units that
normally responds.
1. Check the connection
between the module and
loop-line.
2. Contact an authorised
service office.
•
Minor fault if in no
combination with
other faults
•
Major fault if in
combination with
other faults i.e. Fault
128.
148
DOUBLE
ADDRESS
Loop units
There are two loop
units with the same
address on the loop.
1. Check address of the
units. (Refer to the
S&M** manual.)
2. Rescan or restart the
loop.
Major fault.
149
SHORT
CIRCUIT
CM 4.3
CM 2.2
Short circuit has been
detected on an in- or
output to the affected
module.
Locate and attend to the
short circuit. Then reset the
fault.
Major fault.
CS-PYH
CS-IC10
CS-IC10 Ex
CS-IC22
CS-Isolator
ChargerM
152
PRESENT
NOT
CONFIGUR-
ED
Loop units
The affected loop unit
is not in the system
configuration file.
1. Check the address of the
loop unit. (Refer to the
S&M** manual.)
2. Check the configuration
file.
3. Contact an authorised
service office.
Minor fault.
153
HIGH
CURRENT ON
LOOP
CS-Loop M
To high voltage fault
on the loop-line.
Fault reported when
the measured loop-line
current exceeds the
allowed current.
1. Check the connection
between the loop unit
and the power supply.
2. If not possible to solve
the problem, contact an
authorised service office.
Major fault.
