User Manual 7Fault codes
5100606_CFD5000 T - CM2.2_User Manual_T_EN_2023_E
45
Fault Code
Unit or
Module
Cause Remedy Failure classification
232
INVALID
APPLICA-
TION
Charger M
The bootloader in the
affected module
cannot start the
application due to a
corrupted firmware.
This fault might occur
during a firmware
upgrade.
1. Try to reset the fault.
2. If not possible to reset
try to update firmware
again. (Might demand
for system reboot.)
3. Contact an authorised
service office.
Major fault.
CS-Loop M
CS-Safety M
CS-Com M
Replacement module
has a wrong firmware
version.
1. Update firmware. (Refer
to the S&M** manual.)
2. Contact an authorised
service office.
Loop units
The loop unit
firmware is different
from the CS-Loop
module's major
version. All loop units
on a loop-line shall
have the same
firmware.
233
RELAY
OUTPUT
CS-Safety M
CS-IC22
A relay is broken or in
a state that damages
the relay. (The voltage
over the relay coil is
too high.)
Replace the unit. (Refer to
the S&M** manual.)
Major fault.
234
NO ANSWER
EXTENSION
BUS
RM 4.3
The affected module is
not answering on the
extension bus where it
is connected.
1. Check for cable breaks
on the extension bus.
(Refer to the I&C*
manual.)
2. Contact an authorised
service office.
Major or Minor fault
depending on project
specific function.
238
AIR FLOW
FAULT
CS-PYH
Air flow fault from the
aspiration box
CS-ASP.
Check:
•
If the inlet or outlet
sampling pipe is
blocked.
•
Power feeding from the
external 24 VDC.
Major or Minor fault
depending on project
specific function.
242
SERVICE
TIME
CM 4.3
CM 2.2
CM X
The system has not
been serviced for a
period of time.
Contact an authorised
service office.
Major or Minor fault
depending on service
interval.
Hint!
Instructions for troubleshooting and replacement can be found in the Installation &
Commissioning manual
5
or the Service & Maintenance manual
6
.
5) References to the Installation & Commissioning manual are indicated in the remedy column with the symbol *.
6) References to the Service & Maintenance manual are indicated in the remedy column with the symbols **.
