6. System Setting
14
Software Manual
System Setting Summary
CAUTION
System settings may differ depending on the version. Refer to the supplied CD-ROM (Platform
SDK) for the latest information.
“Shell” Tab
The “Shell” tab provides the following setting items.
Setting tab Setting item Description
Shell
Mini Shell (TASKMAN)
Select a simple shell with no taskbar. (Default)
Explorer Shell (IESHELL)
Select the shell with the taskbar and Start menu as in
desktop versions of Windows.
Shell
Debug Port *1
COM1
Output debug messages to COM1 with SW2-3 set to ON
(message output).
COM2
Output debug messages to COM2 with SW2-3 set to ON
(message output).
*1 Debug port output baud rate : 38400bps, 8bits, No parity, 1stop bit
