Compact FUSION Installation Manual Revision 3.50.2
1. RECOMMENDED FUSING1. RECOMMENDED FUSING
Controllers are equipped with fast acting, branch-rated Class T fuse(s). To keep certifications (UL,
CE, etc) it is important that blown fuses are replaced with fuses of the same size and type as those
originally provided with the controller. The table below shows controller sizes with their installed fuse
size. It is also important to use this chart when external fuses are required.
Frame Size
Fuse Size (Amps)
600 V Rated
CCI P/N for Class T
10A 15 Fast Acting T 0042110-0460-315
25A 30 Fast Acting T 0042110-0460-325
50A 60 Fast Acting T 0042110-0460-350
80A 100 Fast Acting T 0042110-0460-410
100A 125 Fast Acting T 0042110-0460-412
125A 150 Fast Acting T 0042110-0460-415
160A 200 Fast Acting T 0042110-0460-420
Control Concepts carries an inventory of fuses and fuse blocks for purchase.
