COMMANDER SE PARAMETER
DESCRIPTION
PAR. LEVEL 1 DEFAULT
50 / 60 Hz
01 Minimum speed (Hz) 0.0
02 Maximum speed (Hz) 50.0 / 60.0
03 Acceleration rate (s/100Hz) 5.0
04 Deceleration rate (s/100Hz) 10.0
05 Speed reference select A1.A2 / PAd
06 Rated current (A) drive rating
07 Rated speed (RPM) 1500 / 1800
08 Rated voltage (V) 230/400 / 230/460
09 Power factor 0.85
10 Parameter access L1
Changing Parameter 10 to L2 allows access to level 2 parameters from 11 to 44.
LEVEL 2
11 Preset 1 (Hz) 0.0
12 Preset 2 (Hz) 0.0
13 Preset 3 (Hz) 0.0
14 Preset 4 (Hz) 0.0
15 Jog speed (Hz) 1.5
16 Current input mode (mA) 4 - .20
17 Enable negative preset speeds OFF
18 Last trip --
19 Trip before Par.18 --
20 Trip before Par.19 --
21 Trip before Par.20 --
22 Load display units (%/A) Ld (%)
23 Speed display select units (Hz/RPM/units) Fr (Hz)
24 Customer scaling for parameter 23 1.00
25 Security setup 0
26 FWD/REV key enable OFF
27 Power up mode for keypad ref. 0 (zero speed)
28 Parameter cloning mode no (do nothing)
29 Load defaults no (defaults not loaded)
30 Ramp mode 1(standard ramp)
31 Stopping mode 1(ramp to stop)
32 Variable torque select OFF
33 Spinning motor select OFF
34 Positive logic select On (positive)
35 Start / Stop logic setup 0
36 Analogue output select Fr (motor speed)
37 Switching frequency 6kHz
38 Auto tune 0 (no auto tune)
39 Rated frequency (Hz) 50.0 / 60.0
40 Number of poles Auto
41 Serial mode 0 (ANSI)
42 Baud rate 4.8
43 Serial address 1.1
44 Software version --
4
