In modes 2 and 4 the destination parameter is at a value equivalent to 0.0% when the input current is less than 4mA. In modes 3 and 5 the destination
parameter is at a value equivalent to 100.0% when the input current is less than 4mA.
The following modes are available for the analog outputs.
7.16 T8 analog input 3 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range 0.000 to 4.000
Default 1.000
Update rate Background read
7.17 T8 analog input 3 invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate Background read
7.18 T8 analog input 3 destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
7.19 T9 analog output 1 source
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21111
Range Pr 0.00 to Pr 21.51
Default Pr 3.02
Update rate Background read
7.20 T9 analog output 1 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range 0.000 to 4.000
Default 1.000
Update rate Background read
7.21 T9 analog output 1 mode
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0 to 3
Default 0
Update rate Background read
Parameter value Parameter string Mode
0 VOLt Voltage mode
10-20 0 - 20mA
24-20 4 - 20mA
3 H.SPd High speed update mode
