Option program (Opt.Prg) type data block
This type of data block contains a user program from an applications module. Data transfers to copy data to and from a SMARTCARD in this format
are initiated with values from 15yyy to 20yyy in Pr x.00. If the action is not possible because there is no applications category module in the requested
slot then Pr x.00 remains at the value set by the user. If the action is not possible for any other reason a C.SLx trip is produced where x is the slot
number. The possible reasons are:
1. The data block to be read from the card does not exist or the data block is of the wrong type.
2. The data block to be written to the card already exists.
3. A failure has occurred within the Solutions Module and it has stopped the transfer process.
4. The data block written to the SMARTCARD is not clonable. Allow cloning within CTSoft and SyPTPro.
When transferring data between drives the following should be noted:
Parameter transfer failure
When parameter or default difference data is transferred to the drive the parameters are automatically saved to drive EEPROM. If the transfer from
the card fails for any reason the drive produces the appropriate trip. If the failure occurs after the transfer has begun, it is possible that some, but not
all the parameters will have been updated with the card data. However, if the transfer fails the parameters are not saved to drive EEPROM, therefore
only the RAM values will be incorrect. If the drive is powered down and then powered up again the original drive parameters will be restored.
Read-only function
Data blocks with numbers from 1 to 499 can be created or erased by the user. Data block with numbers 500 and above are read-only and cannot be
created or erased by the user. The whole card may also be protected from writing or erasing by setting the read-only flag. If the card or a data block
on the card is read-only, then the operation to erase the whole card is disabled.
Different voltage ratings
If the voltage rating of the source and destination drive are different then the parameters are transferred with the exception of rating dependent
parameters (RA attribute set, see table below), which are left at their default values. In this case a C.rtg trip is given as a warning that this has
happened. It is possible to suppress this warning trip for any data transfer to the drive, including a boot transfer at power-up by setting the warning
suppression flag for the whole card.
Different Solutions Modules installed
If the categories of the Solutions Modules installed to the source drive are different to the destination drive then the parameters are transferred with
the exception of the parameters in the menus of the modules that are different. These parameters are left at their default values. In this case a C.Optn
trip is given as a warning. It is possible to suppress this warning trip for any data transfer to the drive, including a boot transfer at power-up by setting
the warning suppression flag for the whole card.
Different current rating with a parameter file type data block
If the current ratings of the source and destination drive are different and the parameters stored as a parameter file (not differences from default) then
rating dependant parameters are set to their defaults and a C.rtg trip is produced as described above where the voltage ratings are different. It is
possible to suppress this warning trip for any data transfer to the drive, including a boot transfer at power-up by setting the warning suppression flag
for the whole card.
Different current rating with difference from defaults type data block
If the current ratings of the source and destination drives are different, but the parameters are stored as a difference from defaults file, the rating
dependant parameters are transferred from the card to the drive and the appropriate maximums are applied. The C.rtg is still produced unless it is
suppressed. To ensure that the performance of the destination drive is similar to that of the source drive, the speed controller gains and current
controller gains are scaled as shown in the table below. Note that the gain scaling is only applied when the data block number is less than 500.
Parameter number Function
Pr 2.08 Standard ramp voltage
Pr 3.05 Regen unit voltage setpoint
Pr 4.05
- Pr 4.07, Pr 21.27- Pr 21.29 Current limits
Pr 4.24 User current maximum scaling
Pr 5.07, Pr 21.07 Motor rated current
Pr 5.09, Pr 21.09 Motor rated voltage
Pr 5.10, Pr 21.10 Rated power factor
Pr 5.17, Pr 21.12 Stator resistance
Pr 5.18 Switching frequency
Pr 5.24, Pr 21.14 Transient inductance
Pr 5.25, Pr 21.24 Stator inductance
Pr 6.48 Mains loss ride through detection level
Gains Scaling applied
Speed controller gains x Source Pr 11.32 / Destination Pr 11.32
Current controller gains x Destination Pr 11.32 / Source Pr 11.32
