When this bit is set to one the motor 2 parameters in menu 21 become active instead of the equivalent parameters in other menus. Changes will only
be implemented when the drive is disabled. When the motor 2 parameters are active the decimal point that is second from the right on the 1st row of
the display is lit. If this parameter is one when an auto-tune is carried out (Pr 5.12 = 1), the results of the auto-tune are written to the equivalent
second motor parameters instead of the normal parameters. Each time this parameter is changed the accumulator for motor thermal protection is
reset to zero.
Displays the number of the last set of defaults loaded, i.e. 1233, 1244, etc.
This parameter is used to start and stop the Drive Onboard PLC program.
The Drive Onboard Application Lite Ladder Program Status parameter indicates to the user the actual state of the Drive Onboard Application Lite
Ladder Program (not installed / running / stopped / tripped).
11.45 Motor 2 parameters select
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate Background read
11.46 Defaults previously loaded
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1
Range 0 to 2,000
Default Number of defaults loaded, i.e. 1,233 etc.
Update rate Background write
11.47 Drive Onboard Application Lite Ladder Program Enable
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 2
Default 2
Update rate Background read
Value Description
0 Halt the Drive Onboard Application Lite ladder Program.
1
Run the Drive Onboard Application Lite ladder Program (if installed). Any out-of-range parameter writes attempted
will be clipped to the maximum / minimum values valid for that parameter before being written.
2
Run the Drive Onboard Application Lite ladder Program (if installed). Any out-of-range parameter writes attempted
will cause a drive trip.
11.48 Drive Onboard PLC program status
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range -128 to +127
Update rate Background write
Value Description
-n
Onboard Application Lite Ladder Program caused a drive trip due to an error condition while running rung n. Note
that the rung number is shown on the display as a negative number.
0 Onboard Application Lite Ladder Program is not installed.
1 Onboard Application Lite Ladder Program is installed but stopped.
2 Onboard Application Lite Ladder Program is installed and running.
