Menu 17
Parameter
structure
Keypad and
display
Parameter x.00
Parameter
description format
Advanced parameter
descriptions
Serial comms
protocol
Electronic
nameplate
Performance
198 Digitax ST Advanced User Guide
www.controltechniques.com Issue Number: 1
140 Y Program Error - Overflow
141 Y
Program Error - Math Subtraction
Overflow
142 Y Program Error - Math Stack Overflow
User Program math process stack has
overflowed
143 Y File Corruption Error - Consult Factory
144 Y File Corruption Error - Consult Factory
145 Y File Corruption Error - Consult Factory
146 Y File Corruption Error - Consult Factory
147 Y
Program Error - Flash Memory Size
Exceeded
User configuration exceeds available
flash memory size
Eliminate any unused Indexes or Programs
and re-download the PowerTools Pro
configuration
148 Y
Program Error - RAM Memory Size
Exceeded
User configuration exceeds available
RAM memory size
Eliminate any unused Indexes or Programs
and re-download the PowerTools Pro
configuration
153 Y File Corruption Error - Consult Factory
154 Y File Corruption Error - Consult Factory
155 Y File Corruption Error - Consult Factory
156 Y
Program Error - Too Many Wait For
Instructions
No more than nine arguments in Wait
for Instruction
Limit # of arguments and redownloads
157 Y File Corruption Error - Consult Factory
158 Y File Corruption Error - Consult Factory
159 Y File Corruption Error - Consult Factory
160 Y File Corruption Error - Consult Factory
161 Y File Corruption Error - Consult Factory
162 Y File Corruption Error - Consult Factory
163 Y File Corruption Error - Consult Factory
164 Y File Corruption Error - Consult Factory
165 Y File Corruption Error - Consult Factory
166 Y
Program Error - EZMotion Parameter
Write Out of Range
Value written to Motion Processor
parameter in user program is out of
range
171 Y Invalid Slot 1 Selection
Solutions Module selected for Slot 1 in
PowerTools Pro file does not match
actual module type installed
Switch module located in Slot 1 to match
module type selected in PowerTools Pro file.
Alternatively, update the PowerTools Pro
configuration to match the module type
actually installed, and then re-download the
configuration.
172 Y Invalid Slot 2 Selection
Solutions Module selected for Slot 2 in
PowerTools Pro file does not match
actual module type installed
Switch module located in Slot 2 to match
module type selected in PowerTools Pro file.
Alternatively, update the PowerTools Pro
configuration to match the module type
actually installed, and then re-download the
configuration.
173 Y Invalid Motion Processor
PowerTools Pro file does not match the
Motion Processor
Motion Processor fault or incorrect
configuration
174 Y File Corruption Error - Consult Factory
175 Y Module Output Overload
Motion Processor can only supply
20mA maximum total output current. If
this fault occurs, the digital output
device attached to the Motion
Processor outputs is drawing too much
current.
Modify circuitry of devices connected to the
Motion Processor digital outputs so that they
draw no more than 20mA total.
Error
Code
(Pr 17.50)
Cause
Trip?
Error Possible Reason Possible Solution
