21.28 Regen current limit
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 111
Range 0 to MOTOR2_CURRENT_LIMIT_MAX %
Default 300.0
Normal
parameter
Pr 4.06
Update rate Background read
21.29 Symmetrical current limit
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 111
Range 0 to MOTOR2_CURRENT_LIMIT_MAX %
Default 300.0
Normal
parameter
Pr 4.07
Update rate Background read
21.30 Motor volts per 1000rpm (Ke)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 10,000
Default 98
Normal
parameter
Pr 5.33
Update rate Background read
21.31 Motor pole pitch
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2111
Range 0 to 655.35mm
Default 0.00mm
Normal
parameter
Pr 5.36
Update rate Background read
