QUICK‐FITGSM
INSTALLATIONMANUAL

Page18
9.2.4 Table of parameters
Name Comment
OS1 Mode of operation for output 1
OS2 Mode of operation for output 2
OS4 Mode of operation for output 3
OS4 Mode of operation for output 4
OD1 Input 1 direct link to outputs
OD2 Input 2 direct link to outputs
OD3 Input 3 direct link to outputs
OD4 Input 4 direct link to outputs
OD5 NAC direct link to outputs
OP1 Invert control for output 1
OP2 Invert control for output 2
Table 6: Output management parameters
Example:
♦ Direct programming on the SIM card
QUICK-FIT GSM PROGRAMMING TABLE
SIM CARD PHONE BOOK
Name Number Description
OS1 1 Bistable toggle mode
OS2 14 Monostable pulse mode ( 14s pusle )
OD1 1 Input 1 activates output 1
OD4 2 Input 2 activates output 2
OP1 1 Output 1 inverted
Table 7: Output management parameters example
♦ Remote programming by SMS
;OS1=1;OS2=14;OD1=1;OD4=2;OP1=1;
9.3 SECURITY LEVEL - SL
SL parameter from 0 to 5 defines which telephone number stored in the phone book
from TN1 – TN5 can enter into programming and remote control of the QUICK-FIT GSM
(dialing the QUICK-FIT GSM phone number or sending the SMS).
NOTE When the SL level is 0, an access to the QUICK-FIT GSM is possible from any
phone!
IMPORTANT
Before any SL number is programmed the QUICK-FIT GSM can accept
