QUICK‐FITGSM
INSTALLATIONMANUAL

Page16
LN7 NAC list. No. linking (TN1 – TN5) ( see note)
LN8 Log status. No. linking (TN1 – TN5)
LOT Time out for GSM connection.
Table 3: Remote alarm reporting parameters
Note:
When telephone number (calling or messaging QUICK-FIT GSM) is not on the CLIP list, not
acknowledge event occurs (NAC). The telephone number responsible for this event can
be send to TN user for notification.
Example:
♦ Direct programming on the SIM card
QUICK-FIT GSM PROGRAMMING TABLE
SIM CARD PHONE BOOK
Name Number Description
TN1 042376678 1st telephone number
LN1 13 Input 1 reports alarm to TN1 & TN3
LN2 1234 Input 2 reports alarm to TN1 & TN2 & TN3 & TN4
LN7 1
NAC event sent to TN1
LOT 60
Voice connection stay valid for max of 60s, afte
r
this time
Voice connection breaks
Table 4: Remote alarm reporting example
♦ Remote programming by SMS
;TN1=042376678;LN1=13;LN2=1234;LN7=1;LOT=60;
9.1.3 CONTROLLING OUTPUTS BY DTMF
QUICK-FIT GSM can control the outputs with the use of DTMF. This is very useful function
in the intercom application.
To control the outputs the user must press the combination of 2 digits. First digit is used
to select the output (1 to 4), the second digit is used to activate (1) or deactivate (0)
the output. There is a special case when the user can select for first digit (output
selection) number 0. In this case all outputs control by the same time.
Combination must be pressed in 2s interval, and must be 3s apart to be valid.
NOTE
QUICK-FIT GSM must be in voice connection to support DTMF output control!
