QUICK‐FITGSM
INSTALLATIONMANUAL
Page43
13 TECHNICAL SPECIFICATION
Description Value
Power Supply 13,8 - 24V AC/DC
Current consumption - peak 2A
Current consumption - transmitting mode 250mA
Current consumption - idle mode 75mA
Tri band GSM module (QUAD optional) 900/1800 MHz *
PCB dimensions 106 × 89 mm
Unit dimensions 118 × 170 × 60 mm
Call buttons Up to 8
Antenna SMA 1
Weight 810 gr.
Alarm inputs 2 + 2
Alarm outputs (relay) 2
Alarm outputs (open collector) 2
12V DC Power Supply input Y
12/24V AC/DC Power Supply input Y
Anti-tamper protection optional
* Quad Band GSM module optional
