QUICK‐FITGSM
INSTALLATIONMANUAL
Page14
9.1.1.2 ID parameter
ID parameter determines time period of the pulse length to trigger the alarm. The pulse
time can be from 0,5 seconds to 9999 seconds. The default time is 0,5 seconds when the
parameter value is 0.
9.1.1.3 DD parameter
This parameter is used to define the delay between the time that alarm input is trigged
and the time that alarm is reported.
9.1.1.4 Table of parameters
Name Comment
IN1 Mode of operation for input 1
IN2 Mode of operation for input 2
IN3 Mode of operation for input 3
IN4 Mode of operation for input 4
ID1 Input time integration delay on input 1
ID2 Input time integration delay on input 2
ID3 Input time integration delay on input 3
ID4 Input time integration delay on input 4
DD1 Time delay for alarm reporting on input 1
DD2 Time delay for alarm reporting on input 2
DD3 Time delay for alarm reporting on input 3
DD4 Time delay for alarm reporting on input 4
Table 1: IN, ID and DD parameters
Example:
♦ Direct programming on the SIM card
QUICK-FIT GSM PROGRAMMING TABLE
SIM CARD PHONE BOOK
Name Number Description
IN1 0 Alarm activated by connecting to GND
IN2 4 Alarm activated by connecting to GND + RST SMS
ID1 10
Input 1 has to be valid for 10 second to trigger the
alarm
ID2 0
Input 2 has to be valid for 0,5 second to trigger the
alarm
DD1 0 Reporting of the alarm on input 1 is delayed by 0s
DD2 15 Reporting of the alarm on input 1 is delayed by 15s
Table 2: IN, ID, DD parameters example
