4 START UP
⇒ Insert SIM card to be used for QUICK-FIT GSM into a mobile phone that allows the
use of the network the SIM card is on. Make sure the SIM card works before you
start!!!
IMPORTANT
ERASE THE PIN CODE IF THE PHONE ASKS!
⇒ Insert SIM card in QUICK-FIT GSM device. The unit must be switched OFF when you
insert the SIM!
⇒ Connect alarm inputs if you need & relay outputs to gates / doors etc
⇒ Connect the antenna to antenna connector
⇒ Connect power supply (12-24V AC or DC) to QUICK-FIT GSM
⇒ Wait until LED3 display is turned ON (green) and LED1 (blue) starts flashing. This
is usually set within 30 secs or less
⇒ You will hear a beep every 10 secs while it looks for the network and 3 quick
beeps when it connects
⇒ QUICK-FIT GSM unit is now ready to use
IMPORTANT
Before sending any SMS commands to QUICK-FIT GSM device, you must wait for
it to connect
