♦ Remote programming by SMS
;ATN1=040713470;ATN2=+38643364850;RTNA=30;CTN1=040414414;CTN2=04
2340880;RTNC=40;
9.7 CLIP
CLIP is used to provide the “free of charge” options to control the outputs.
9.7.1 CLPEN parameter
Parameter used to enable CLIP functionality.
9.7.2 CLPOU parameter
Parameter used to choose which output will be controlled by the CLIP functionality.
9.7.3 CLPI parameter
This parameter, if set, is a precondition for CLIP function to control the output.
9.7.4 CLP1 … CLP100 parameter
Set of telephone number, which can control the output. The number not on CLP list is
not able to control the output using clip functionality.
9.7.5 Table of parameters
Name Comment
CLPEN Enable CLIP functionality
CLPOU Control output pin when CLIP event
CLPI CLIP input activation condition
CLP1 CLIP number 1
. .
. .
. .
CLP100 CLIP number 100
Table 18: CLIP parameters.
