RTNE Button 5, time out control for voice connection.
SDNE Button 5, DTMF number to send.
SDDE Button 5, delay for DTMF number to send.
TZSE Button 5, time zone start period.
TZEE Button 5, time zone end period.
FTN1 Button 6, Telephone number 1.
FTN2 Button 6, Telephone number 2.
FTN3 Button 6, Telephone number 3.
FTN4 Button 6, Telephone number 4.
FTN5 Button 6, Telephone number 5.
RTNF Button 6, time out control for voice connection
SDNE Button 6, DTMF number to send.
SDDE Button 6, delay for DTMF number to send.
TZSE Button 6, time zone start period.
TZEE Button 6, time zone end period.
GTN1 Button 7, Telephone number 1.
GTN2 Button 7, Telephone number 2.
GTN3 Button 7, Telephone number 3.
GTN4 Button 7, Telephone number 4.
GTN5 Button 7, Telephone number 5.
RTNG Button 7, time out control for voice connection
SDNG Button 7, DTMF number to send.
SDDG Button 7, delay for DTMF number to send.
TZSG Button 7, time zone start period.
TZEG Button 7, time zone end period.
HTN1 Button 8, Telephone number 1.
HTN2 Button 8, Telephone number 2.
HTN3 Button 8, Telephone number 3.
HTN4 Button 8, Telephone number 4.
HTN5 Button 8, Telephone number 5.
RTNH Button 8, time out control for voice connection
SDNH Button 8, DTMF number to send.
SDDH Button 8, delay for DTMF number to send.
TZSH Button 8, time zone start period.
TZEH Button 8, time zone end period.
Table 16: Intercom parameters.
Example:
♦ Direct programming on the SIM card
QUICK-FIT GSM PROGRAMMING TABLE
SIM CARD PHONE BOOK
Name Number Description
ATN1 040713470 Button 1, Telephone number 1.
ATN2 +4474336480 Button 1, Telephone number 2.
RTNA 30 Button 1, time out control for voice connection.
CTN1 040414414 Button 3, Telephone number 1.
CNT2 042340880 Button 3, Telephone number 1.
RTNC 40 Button 3, time out control for voice connection.
Table 17: Intercom parameters example.
