Manuale di Istruzione

Instruction Manual

04/02/2015 58-C0181/DGT Rev. 2 EN

2.3 Main characteristics

• Impact energy: 2.207 Nm

• Measurement range: da 10 a 100 N / mm2

• High contrast graphic display 128x64 pixel and 6-key keyboard

• Test results in numerical and graphic format

• Test procedure according to EN 12504-2 and ASTM C805

• Test procedure can be customized by the user

• Memory storage capacity: 2 Mb

• Data saving and download to PC via USB port

• PC software included

• Integrated ion-lithium battery 1600 mAh capacity

• Measure and display of the test angle thanks to the integrated triaxial inclinometer

• Correlation curves between rebound index and compression resistance user-

selectable

• Correlation curves between index and compressive strength user customizable

• Automatic conversion of rebound index and compressive strength equivalent MPa;

N / mm2; kg / cm2, psi

• Calculation of means, standard deviations and discard of non significant values

• Verification of compliance with the standard in use

• Battery charger multi-voltage / multi-frequency: 110-240V / 50-60Hz / 1Ph

• Battery charge time: 4 hours. We recommend charging the battery even in case of

limited use or after prolonged inactivity.
