Manuale di Istruzioni
Instruction Manual
58-C0181/DGT Rev. 2 EN 04/02/2015
41
3.4.2.2 DOWNLOAD MEASUREMET menu
After connecting the instrument to the PC and checking that it is CONNECTED, press
the icon to download the test stored into the instrument memory, these tests can
be displayed on the instrument in the 3.2.5 menu.
Fig. 3-47
For each report here are the data shown:
• ID: consecutive number assigned to each stored tests
• Date and Time: date and teime of the execution of the test
• Impacts: number of strokes carried out
• Results: measured rebound index
• Angles: referred to each measurement taken, measured by the internal inclinometer
• Average rebound: mean value of the measured rebound index
• Standard deviation: calculated from the gathered rebound indexes
• Average angle: mean value of the angles measured by the internal inclinometer
• Standard: reference standard selected for the test session
• Conversion curve: conversion curve selected for the test session
• Compressive strength: value automatically estimated by the instrument
• Shape factor: selected coefficient
• Age factor: always set to 1. Not available at the moment
• Correction factor: selected coefficient.
