Appendix D—Outline Dimensions
Model 291 with 107 Mounting (Motor Frames 254T and Up)
42 (1,067)
15-3/4 (400)
26 -7/16 (672)
20 (508)
17 (432)
9-11/16
(246)
7-3/4
(197)
19-3/16
(487)
31-13/16
(808)
Overall
33-15/16
(863)
Overall to
optional
relief valve
3-7/8
(98)
4
(102)
4
(102)
1-1/4
(32)
1-1/8
(29)
1-1/2
(38)
5
(127)
5-5/16
(135)
4-3/8
(111)
Liquid drain
1/4" NPT
Strainer
Inlet / Outlet
4-way valve
1" NPT
Suction
Pressure
Gauge
Discharge
Pressure
Gauge
