Instruction for use
29
DANGER: While in reverse gear, always check to see that there are no obsta-
cles and/or persons in the vicinity.
3.5.4 Admissible Slopes
fig. 18 a– Maximum admissible slopes
In figure 7 the maximum values for the latitudinal and longitudinal slopes of the
terrain are shown on which it is possible to work. These conditions must never be
surpassed to avoid the risk of overturning.
.
DANGER: Always avoid working on terrain with slopes that are greater than
those prescribed to avoid the possibility of overturning with possible serious
consequences for the safety of the operator.
In every case, but especially when working on slopes, it is important that the ter-
rain is solid and stable.
3.5.5 Travelling on Slopes
DANGER: Completely avoid working on terrains that have lateral slopes of
more than 10° and longitudinal slopes of more than 20° to avoid the possi-
bility of overturning with serious consequences for the safety of the opera-
tor.
