Instruction for use
36
3.9.3 Use of the Self-loading
Your machine may be equipped with a self-loading mechanism consisting
of an anterior bucket that has a hydraulic command.
.
CAREFUL: During movement the auto-loading device must remain raised
above the surface of the land to avoid collision with the terrain and must be
in a position that does not obstruct visibility.
Loading: To be able to load the body using the auto-loading tool, you
must follow this procedure:
advance the machine towards the pile of material maintaining the ben-
na in a horizontal position;
raise the shovel by pulling the lever towards yourself until you have
poured the contents into the body.
Repositioning: Push the lever forwards until the bucket has lowered to
the correct height from the ground.
Floating (auto-levelling): the auto-loading tool may also be used to func-
tion as an auto-levelling device, useful, for example for levelling ground.
To block the bucket in the floating position you must push the auto-
loading lever forward past the lowering position until you have heard a
click (the lever remains in stable position).
CAREFUL: During the driving and movement of the machine, the self-loading
device must not remain the the floating position.
