Instruction for use
33
DANGER: In the case that you may have to use the emergency brake, con-
sider that this causes the drive mechanism to block instantaneously and may
cause a loss of control of the machine.
WARNING: After the emergency brake intervention, have the integrity and
the working order of the device verified: a continued use of the machine
with an inefficient device could be dangerous for your own safety and that of
others.
3.8 TRANSPORTING LOADS
PROHIBITED: It is strictly prohibited to surpass the load capacity limits indicated in
the table on page 17.
3.8.1 Construction Body (Dumper)
The machine is equipped with a “dumper” type body to transport inert and solid
materials, suitable mainly to be used for construction work.
3.8.2 “Farming” Type Body”
Upon request, your machine may be fitted, in place of the “dumper” type body,
with a body that has sides that can be opened, and
is suitable to transport farming materials.
The opening of the sides allows one to enlarge the
loading surface to be able to transport cumbersome
objects. To obtain a larger loading surface, work
with one side at a time as follows (see fig. 56):
Open two anterior hooks “C”, lower the anterior
side “D” and take it out;;
Loosen the two wheels “A” positioned under the
loading surface;
Take out the two supports “B” from their hous-
ings;
Open the posterior hook “E” and lower the left lateral side “F” making coincide
the notches of the supports in the holes “G”;
Repeat the operation on the other side;
Be sure that the sides are blocked and position the load so that it will not fall:
if possible tied it.
fig. 22 – Farming type body
